Azure SQL Database is one of the most used services in Microsoft Azure, and we use it a lot in our projects. It is basically SQL Server in the cloud, but fully managed and more intelligent. There is another service in Azure that is kind of similar, but not quite: Azure SQL Data Warehouse. Azure SQL Data Warehouse uses a lot of Azure SQL technology, but is different in some profound ways.
As we slowly move from on-premises data warehouses with Microsoft SQL Server to cloud data warehouses in Microsoft Azure, we need to know more about the various options in Azure. You probably already used an Azure SQL Database, but Microsoft also introduced Azure SQL Data Warehouse.
What are the differences Between Azure SQL DB and Azure SQL Data Warehouse:
1) Purpose: OLAP vs OLTP
Although both Azure SQL DB and Azure SQL DW are cloud based systems for hosting data, their purpose is different. The biggest difference is that SQL DB is specifically for Online Transaction Processing (OLTP). This means operational data with a lot of short transactions like INSERT, UPDATE and DELETE by multiple people and/or processes. The data is most often highly normalized stored in many tables.
On the other hand SQL DW is specifically for Online Analytical Processing (OLAP) for data warehouses. This means consolidation data with a lower volume, but more complex queries. The data is most often stored de-normalized with fewer tables using a star or snowflake schema.
2) Achitecture
In order to make the differences more clear a quick preview of the architecture of Azure SQL Data Warehouse, where you see a whole collection of Azure SQL Databases and separated storage. The maximum number of compute notes at the moment is 60.
3) Storage size
The current size limit of an Azure SQL Database is 4TB, but it has been getting bigger over the past few years and will probably end up around 10TB in the near future. On the other hand we have the Azure SQL Data Warehouse which has no storage limit at all (only the limit of your wallet), because the storage is separated from the compute.
3) Pricing
The pricing is also quite different. Where Azure SQL DB starts with €4,20 a month, Azure SQL DW starts around €900,- a month excluding the cost of storage which is included in SQL DB. The storage costs for Azure SQL DW are around €125,- per TB per month. And the maximum costs of a single SQL DB is around €13500,- where SQL DW ends around a massive €57000,- (excl. storage). But when you take a look at the architecture above, it should be no surprise that SQL DW is more expensive than SQL DB, because it consists of multiple SQL DBs.
However, SQL DW has one big trick up its sleeve that SQL DB hasn't: you can pause it completely and then you only pay for storage. If you start your SQL DW with your ETL job and pause it right after you processed your Azure Analysis Services then you only need it a small percentage of the month.
4) DTU vs DWU
SQL DB has 15 different pricing tiers which specify the number of Database Transaction Units (DTU) and the storage size/type:
Basic
Standard (S0, S1, S2, S3)
Premium (P1, P2, P3, P4, P6, P11, P15)
Premium RS (PRS1, PRS2, PRS4, PRS6)
Basic has only 5 DTUs and the highest number of DTUs is, at the time of writing, 4000.
The term DTU is a bit vague. It is a mysterious combination of RAM, CPU and read-write rates, but basically if you want to double the performance of your current database you just need to double the number of DTU's for your database.
SQL DW has 12 different pricing tiers and uses Data Warehouse Units (DWU) to specify the performance level.
DWU100, 200, 300, 400, 500, 600, 1000, 1200, 1500, 2000, 3000, 6000
The term DWU is a little less vague, because if you divide that number by 100 you have the number of compute nodes available for that pricing tier. On the other hand the exact combination of CPU, memory and IOPS per compute note is unknown.
Because both services have a different purpose it is a bit strange to compare the hardware, but according to this MSDN blog post 1 DWU is approximately 7,5 DTU.
But there is also some similarity: for both services you can use the same script to change the pricing tier on the fly to either give the performance a real boost when needed or the save money in the quiet hours.
5) Concurrent Connection
Although SQL DW is a collection of SQL Databases the maximum number of concurrent connections is much lower than with SQL DB. SQL DW has a maximum of 1024 active connections where SQL DB can handle 6400 concurrent logins and 30000 concurrent sessions. This means that in the exceptional case where you have over a thousand active users for your dashboard you probably should consider SQL DB to host the data instead of SQL DW.
For more details see the SQL DB Recource Limitations and SQL DW Recource Limitations.
6) Concurrent Queries
Besides the maximum connections, the number of concurrent queries is also much lower. SQL DW can execute a maximum of 32 queries at one moment where SQL DB can have 6400 concurrent workers (requests). This is where you see the differences between OLTP and OLAP.
For more details see the SQL DB Recource Limitations and SQL DW Recource Limitations.
7) PolyBase
Azure SQL Data Warehouse supports PolyBase. This technology allows you to access data outside the database with regular Transact SQL. It can for example use a file in an Azure Blob Storage container as a (external) table. Other options are importing and exporting data from Hadoop or Azure Data Lake Store. Although SQL Server 2016 also supports PolyBase, Azure SQL Database does not (yet?) support it.
8) Query language differences
Although SQL DW uses SQL DB in the background there are a few minor differences when quering or creating tables:
SQL DW cannot use cross databases queries. So all your data should be in the same database.
SQL DW can use IDENTITY, but only for INT or BIGINT. Moreover the IDENTITY column cannot be used as part of the distribution key.
Also see this SQL DW list of unsupported table features.
9) Replication
SQL DB supports active geo-replication. This enables you to configure up to four readable secondary databases in the same or different location. SQL DW does not support active geo-replication, only Azure Storage replication. However this is not a live, readable, synchronized copy of your database! It's more like a backup.
10) In Memory OLTP tables
SQL DB supports in-memory OLTP. SQL DW is OLAP and does not support it.
11) Always encrypted
SQL DB supports Always Encrypted to protect sensitive data. SQL DW does not support it.
